Sectional garage doors

Design and characteristics of gates

General information

The Beditom sectional garage door is designed for door openings in single family housing. It consists of horizontal and vertical, ceiling-attached tracks and steel, isolated door curtain. The construction is made of galvanized steel elements. The door is fitted with circumferential seal, also in between the segments. The door curtain segments are isolated with a non-freon polyutherane foam. 40 mm. The doors are available in manual and automatic versions.

Leads

Made out of profiled, galvanized steel elements which prevent the nylon guide rollers from falling out. The horizontal leads are fitted with integrated side seals, along with upper and lower seals which create a circumferential sealing. The vertical leads are fitted with bracing profile and are adapted to suspensions matched to the size of the door and construction type in order to ensure stability and stiffness during usage.

Door balancing

The doors are available in two different balancing types.

  • The first torsion spring system for leads: STL300, NLH190, NLH75, LH 200 mounted on lintel barrel or behind horizontal leads. Galvanized torsion springs designed for min. 20.000 cycles. It is possible to produce torsion springs designed for a greater amount of cycles, e.g.: 50.000, 100.000. Spring fracturing safeguards (SFS) are installed by default.
  • he second torsion spring system for leads: EXT, EXT Renovatio, installed along the vertical leads in the amount of 2 or 3 per side, galvanized, designed for 25.000 cycles.

Door curtain

Door curtain is made out of 40 mm thick galvanized steel sheet segments (panels) with non-freon polyutherane foam core isolation. The shape of the edge of a segment is profiled in a way which ensures finger trapping protection. The edges of the segments are fitted with galvanized steel fittings which reinforce the construction. Additional construction elements are attached to the fittings, e.g. steel side hinges with nylon bearing rolls which drive the gate on the leads. Moreover, for each size od the door, middle hinges which ensure adequate stability for the door courtain. The gates are fitted with a system of durable, flexible, weather-resistant gaskets, which are , which are located on the whole perimeter of the door and between the segments. Seals between the upper panel and the lintel are provided by a seal mounted to the upper panel or to the lintel. The bottom panel is fitted with a gasket made of special modified EPDM material, which adheres to the bottom panel.

Types of drives

PARAMETERS OF THE GARAGE OPENING

B - hole width, ordering size

Bf - width of the entrance opening after the door is mounted

H - hole height, ordering size

Hf - height of the entrance opening after the door is mounted

Hp - height of the lead from the garage floor

a - left side jamb width

b - right side jamb width

d - lintel height

P - horizontal leads length

pg - garage depth

Pn - length of the drive incl. rail

TYPES OF GARAGE LEADS

STL 300 lead – front torsion springs

Required construction parameters [mm]:

a,b min = 100

d min = 300 (manual opening)

d min = 350 (automatic opening,

manual opening with an OPTIMUM or STANDARD lock)

Bf = B – 40 (side gasket diameter)

Hf = H – 20 (upper gasket diameter)

p = H + 450 (manual opening)

Pn = H + 1350 (automatic opening)

Hp = H + 150

NLH 190 lead – front torsion springs

Required construction parameters [mm]:

a,b min = 95

d min = 190 (manual opening)

d min = 190 (automatic opening,

manual opening with an OPTIMUM or STANDARD lock)

Bf = B – 40 (side gasket diameter)

Hf = H – 100 (manual opening)

Hf = H – 20 (automatic opening, upper gasket diamter)

P = H + 640 (manual opening)

Pn = H + 1350 (automatic opening)

Hp = H – 40

NLH 75 lead – back torsion springs

Required construction parameters [mm]:

a,b min = 95

d min = 75 (manual opening LUX lock)

d min = 115 (automatic opening,

manual opening with an OPTIMUM or STANDARD lock)

Bf = B – 40 (side gasket diameter)

Hf = H – 75 (manual opening)

Hf = H – 20 (automatic opening, upper gasket diamter)

P = H + 770 (manual opening)

Pn = H + 1350 (automatic opening)

Hp= H – 40

Caution NLH75 lead for an additional price.

LH 200 lead – front torsion springs

Required construction parameters [mm]:

a,b min = 100

d min = 200 (manual opening)

d min = 250 (automatic opening)

manual opening with an OPTIMUM or STANDARD lock)

Bf = B – 40 (side gasket diameter)

Hf = H – 175 (manual opening)

Hf = H – 20 (automatic opening, upper gasket diamter)

P = H + 480 (manual opening)

Pn = H + 1350 (automatic opening)

Hp= H – 40



Advantages of the new leads systems:

- solid and durable construction, compliant with the European norms

- easy installation "single tool principle"

- brief installation (even up to 60 min) thanks to the appropriately prefabricated door construction which allowes for a very simple and easy installation (see installation instructions)

- logistics-friendly

EXT lead – tension springs

Required construction parameters [mm]:

a,b min = 90

d min = 100 (manual opening LUX lock)

d min = 115 (automatic opening)

Bf = B – 40 (side gasket diameter)

Hf = H – 250 (manual opening)

Hf = H – 20 (automatic opening, upper gasket diamter)

P = H + 575 (manual opening)

Pn = H + 1350 (automatic opening)

Hp = H – 40

EXT Renovatio leads – tension springs

Br – ordering width for doors with EXT Renovatio leads

Hr – ordering height for doors with EXT Renovatio leads

wymagane parametry zabudowy [mm]:

0 ⩾ a,b ⩾ 70

d min = 100 (manual opening LUX lock)

d min = 115 (automatic opening)

Br = B – 200

Bf = Br – 40 (side gasket diameter)

Hf = Hr – 250 (manual opening)

Hf = Hr - 20 (autmatic opening, upper gasket diameter)

P = Hr + 575 (manual opening)

Pn = Hr + 1350 (automatic opening)

Hp = Hr – 40



Door installation in the opening (a,b =0):

Door installation behind the opening (0 > a,b ⩾ 70):

Security features

Proper use of doors depends not only on the necessary maintenance and service, but also on proper design of the door meeting the requirements of the customer, taking into account its building options.

For over 20 years as a leader and precursor of technical solutions, we have been equipped our gates so that they meet the strict and the latest safety requirements of European Standards. Our products are labelled with the CE label.

Such devices and solutions include, amongst others:

1. Specially profiled panels (inside and outside) which prevent fingers from getting jammed in joints as well as in places where the hinges are installed.
2. Specially profiled guides which prevent the rollers from falling out.
3. The cable breakage protection protects against uncontrolled falling of the door leaf in case of the event of steel cables breakage.
4. Spring breakage protection in case of breakage of one of the torsion springs ensures maximum safety.
5. The covers of the vertical guides cut them off from direct contact with moving elements on the vertical guide.
6. The anti break-in blockade adds another level of protection against unwarranted door opening from outside
7. Patented mechanical anti-burglary lock forthe automatic gate
8. Possibility of connecting alarm system to the automatic gate
9. Overload protection upon contacting an obstacle stops the gate and moves it back up.
10. Photocells ensure that the gate is stopped and returned to the open position if it contacts an obstacle on its path.

Additional equipment options

Glazing

okno okrągłe bulaj S1

S1 type window

Round, stainless, 240 mm diameter with safety glass.

okno kwadratowe S3

S3 type window

Square, stainless, dimensions: 230x230 mm.

Okno prostokątne P1

P1 type window

Black, plastic, dimensions: 610x203 mm.

Okno prostokątne P2

P2 type window

Rectangular, black, plastic, dimensions: 640x336 mm.

Okno prostokątne P3

P3 type window

Rectangular, external, dimensions: 490x324 mm.
Filling: double acrylic glass
Frame: plastic
Colours: white RAL 9016, black RAL 9005, brown RAL 8014, woodgrain structure

segment Aludoor

Aludoor Glazing

Full glazing of gate segment. The gate segment is made of aluminum profiles

Locks

Zamek Lux

LUX type lock

Black lock equipped with a patented insert

Zamek Optimum

OPTIMUM type lock

Black lock equipped with a patented insert

Zamek Standard

STANDARD type lock

Black horizontal lock with a patented insert

Other


Latches

Side latch with mechanical, vertical lock.


Ventilation grilles

Black, dimensions: 344x138mm.


Gate wicket

The gate wicket allows passage without having to open the whole gate


Decorative muntins

Various window designs with muntins
